SICK LD-LRS3601 2D LIDAR Sensors (5 Hz ~ 15 Hz, 0.125°, 2.5 m ~ 250 m)

Application: Indoor

Light source: Infrared (905 nm)

Laser class: 1 (IEC 60825-1:2014, EN 60825-1:2014)

Aperture angle: Horizontal 360°

Scanning frequency: 5 Hz ... 15 Hz

Angular resolution: 0.125°, Interlaced: 0.0625 / 0.125° / 0.1875° / 0.25° / 0.375° / 0.5° / 0.75° / 1°

Working range: 2.5 m ... 250 m

Scanning range: At 10% remission 80 m / At 90% remission 250 m

Connection type: 1 x 20-pin Harting plug

Supply voltage: 24 V DC, ± 15 %

Power consumption: 36 W, + 140 W heating

Housing: PU (polyurethane rigid integral foam)

Housing color: Gray (RAL 7032)

Enclosure rating: IP67

Protection class: III

Weight: 9.1 kg

Dimensions (L x W x H): 250 mm x 350 mm x 391.1 mm
