Nichicon UVP1H220MPD1TA Bi-Polar/Non-Polar Electrolytic Capacitors 50volt 22uF 20% 85DEG 3.5mm L/S
Manufacturer: Nichicon Model: UVP1H220MPD1TA - Contact
Life: 2000 Hour
Length: 11.5 mm
Diameter: 8 mm
Tolerance: 20 %
Lead Style: Straight
Capacitance: 22 uF
Unit Weight: 1.374 g
Lead Spacing: 3.5 mm
REACH - SVHC: Details
Ripple Current: 89 mA
Leakage Current: 33 uA
Termination Style: Radial
Voltage Rating DC: 50 VDC
Dissipation Factor DF: 0.14
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
