TRACO Power TEP 160-2416 Isolated Product Type: DC/DC; Package Style: 2.3"x1.9"; Output Power (W): 160; Input Voltage: 16.5-36 VDC; Output 1 (Vdc): 28; Output 2 (Vdc): N/A; Output 3 (Vdc): N/A
Manufacturer: TRACO Power Model: TEP 160-2416 - Contact
Width: 57.9 mm
Height: 12.7 mm
Length: 61 mm
Industry: Industrial
Application: Telecom, Industry Control and Railway Systems for on Board Power Distribution
Unit Weight: 105 g
Output Power: 160 W
Input Voltage: 24 V
Mounting Style: Chassis
Isolation Voltage: 2.25 kV
Number of Outputs: 1 Output
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 5.5 A
Output Voltage-Channel 1: 28 V
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 40 C
