Standard: CISPR16-1-4 Ed.3.2
Frequency Range: 30 MHz-300 MHz
Max, AC Voltage（L-PE): 250 V
Max. DC Voltage（L-PE): 400 V
Max. Current: 16 A
EUT Port Type: 4 mm Banana(L/N/PE)
AE Port Type: 4 mm Banana(L/N/PE)
Input Impedance (EUT End):
L line 30 MHz to 300 MHz: 250Ω ± 20 %
N line 30 MHz to 300 MHz: 150Ω ± 20 %
PE line 30 MHz to 300 MHz: 90Ω ± 20 %
Phase（EUT End, L line, N line):
30 MHz to 108 MHz: 0 ± 11.5°
108 MHz to 300 MHz: 0 ± 25.0°
Isolation (AE-EUT):
30 MHz to 300 MHz: > 40 dB
- General Parameters:
Dimension: 250 mm (L) ×16 mm (W) ×10 mm（H）
Weight: 4.0 kg
Ambient Temperature: 15 ℃–35 ℃
Relative Humidity: 45%–75%
Atmosphere Pressure Range: 86 kPa–106 kPa
