Integrating sphere size: Φ40mm
Light source: Combined full-spectrum LED light source, UV light source
Spectroscopic method: Planar grating
Sensor: Silicon photodiode arrays (dual row 32 groups)
Wavelength range: 400~700nm
Wavelength interval: 10nm
Semiband Bandwidth: 10nm
Measurement range: L:0~120
Reflectivity: 0~200%
Measurement aperture: Dual apertures: Φ8mm, Φ4mm
Focusing method: Optical Focus
Color space: CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,βxy,DIN Lab9,DIN Lab99 Munsell(C/2)
Observer angle: 2°/10°
Illuminant: D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30)
Display Accuracy: 0.01
Measurement time: Approx. 1.5s (Measure SCI & SCE about 3.2s)
Measurement method: Single measurement, average measurement (2~99 times)
Locating method: Camera locating, stabilizer locating
Size: LxWxH=81x71x214mm
Weight: About 460g
Battery power: Lithium battery, 6000 times in 8 hours
Illuminant life span: 5 years, more than 3 million times measurements
Display: TFT true color 3.5inch, capacitive touch screen
Data port: USB, Bluetooth® 5.0
Data storage: 1000 standard samples, 30,000 samples (a piece of data can include SCI/SCE at the same time), APP mass storage
Language: Simplified Chinese, English, Traditional Chinese
Operating temperature range: 0~40℃, 0~85%RH (no condensation), altitude< 2000m
Storage temperature range: -20~50℃, 0~85%RH (no condensation)
Standard Accessories: Power adapter, data cable, manual, SQCX quality management software (official website download), black and white calibration box, protective cover, wrist strap, dual aperture: Ø8mm + Ø4mm platform aperture, MOBCCS APP (official website download)
Optional Accessories: USB LxWxH=81x71x214mm printer, powder test box, Bluetooth micro printer, holder base
