Accuracy: ±1% of FS at calibration temperature and pressure
Calibrations: Performed at standard conditions [14.7 psia (101.4 kPa) and 70 °F (21.1 °C)] unless otherwise requested
Repeatability: ±0.25% of full scale
Temperature coefficient: 0.1% of full scale / °C
Pressure coefficient: 0.01% of full scale / psi (0.07 bar)
Gas and ambient temp.: 32 °F to 122 °F (0 °C to 50 °C).14 °F to 122 °F (-10 °C to 50 °C) - Dry gases only
Optimum gas pressure: 25 psig (1.73 bars)
Maximum gas pressure: 1000 psig (70 bars) maximum. Standard calibration is at 20 psig (1.4 bars) inlet pressure
Time constant: Qmax = 10 L/min: 300 ms
Response time: Qmax = 10 L/min: Approximately 1 second to within ±2% of set flow rate for 25% to 100% of full scale flow
Connections: 1/4" compression fittings
Transducer input power: +15 ±5% Vdc, 80 mA max, 1.2W; -15 ± 5% Vdc, 200 mA max, 3W
