AARONIA SPECTRAN HF RSA 5000 Low Frequency Remote Spectrum Analyzer

ManufacturerAARONIA(View more products from this manufacturer)

ModelRSA5000

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Frequency range: 1Hz to 1MHz (30MHz)
Analog Input: 2µV to 200mV (typ.)
With opt. DDC:
200nV to 200mV (typ.)
Resolution (RBW): 0,3Hz to 1MHz
(1-3-10 step)
Units: Volt
Detectors: RMS, Min/Max
Demodulator: AM, FM
Input: N input (f)
Accuracy: 3% (typ.)
Interface: USB 2.0/1.1/LAN
Dimensions (L/W/D): 19 inch rack mount
Weight: 3450gr
Warranty: 2 years

Integrated PC:

CPU: Intel Celeron G530 2,4GHz
RAM: 2x2GB SO-DiMM DDR3, 1066MHz
HDD: 320GB (5400rpm)
External Ports: 2x USB 2.0, 2x USB 3.0, 1x Audio, 1x 10/100/1000 Mb/s Ethernet, 1x DVI-I (Analog,Digital), 1x HDMI, 1x eSATA
Power supply: 19,5V (7,9A max.)
Operatingsystem: Linux

Highlights:

Internet flash software updates
High-performance DSP (Digital Signal Processor)
Real-time remote control via USB
Audio out for the use of PC based FFT analyzer software
Very thick (3mm) aluminum housing offering very good screening
Free Mac OS, Linux and Windows software

Application examples

Included in delivery

Options

Accessories

Downloads

Initiates file download

Datasheet (pdf)
