Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Qualification: AEC-Q100
Mounting Style: SMD/SMT
SR - Slew Rate: 450 mV/us
Number of Channels: 2 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 4 V
Ib - Input Bias Current: 10 nA
Operating Supply Current: 500 uA
Vcm - Common Mode Voltage: 36 V
Ios - Input Offset Current: 10 nA
Output Current per Channel: 16 mA
Vos - Input Offset Voltage: 50 uV
GBP - Gain Bandwidth Product: 1.2 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 25 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 110 dB
PSRR - Power Supply Rejection Ratio: 130 dB
