Voltage Supply: Single-phase ~220V±10% / 50Hz±10%, power <800W
Battery Types: 18650, 21700, 26650, 32650, 32700 (other sizes available)
Receiving Channel: 10 sorting & matching group channels, 1 unqualified product channel, arbitrary sorting values can be set for each channel
Test Parameters: AC internal resistance, DC voltage
Internal Resistance Test: Test range 80mΩ, accuracy ±0.5%rdg, display resolution 0.01mΩ
Voltage Test: Test range 8V, accuracy ±0.015%rdg, display resolution 0.01mV
Sorting Speed: 80ppm
AI Set Function: Intelligent one-button setting, specially designed for new battery pack functions
Dimensions: L1430mm × W660mm × H1350mm
Weight: <200Kg
Features
1.This Products with high precision internal resistance,Voltage,automatic test system.
2.The device is set according to the settings Internal resistance voltage,
3 .High production efficiency, very easy to operate.
4.Can be docked with automatic veneer cushion machine.
