Working Power: Three-phase five-wire system AC380V±10%, 50Hz
Working Environment: Temperature 0–40°C, relative humidity ≤80%
Heat Dissipation Method: Natural air intake and upward exhaust
Channel Parameters:
Voltage Measuring Range: 0–5V, 1mV resolution
Battery Voltage Range: Charge 0–4.5V; Discharge 4.5–2V
Constant Voltage Range: 2.5V–4.5V
Voltage Accuracy: ±(1‰ reading + 1‰ full scale)
Current Accuracy: ±(1‰ reading + 1‰ full scale)
Software Functions:
Control Mode: Computer-connected equipment operation, FCL control
Communication Mode: RS485, baud rate 57,600
Process Setting: Maximum 32 working steps and 256 cycles
Charging Mode: Constant current, constant voltage
Charging Cut-off Conditions: Voltage, current, time, capacity
Discharge Mode: Constant current
Discharge Cut-off Conditions: Voltage, time, capacity
Protection Functions: Overvoltage, undervoltage, overcurrent, undercurrent, overcapacity, etc.
Time Range: Adjustable from 0 to 30,000 minutes
Time Accuracy: ≤±1‰
Sampling Inspection Period: ≤8S
Minimum Data Recording Frequency: ≤8S
Battery Sorting: By capacity, time, discharge platform, etc.
Data Processing: Data, graphs, and cycle diagrams
Features
Each channel can be started and stopped at a single point, and the response speed is fast.
The operation is simple, convenient and intuitive
Modular design, easy to maintain.
The digital current and voltage automatic calibration function
Using network connection and SQL database
The hardware technology is advanced, stable and durable.
