Overcharge Protection: 0–5V ±5mV
Overcharge Protection Release: 0–5V ±5mV
Over-discharge Protection: 0–5V ±5mV
Over-discharge Protection Release: 0–5V ±5mV
Over-discharge Protection Current Value: 1A–200A ±0.1 (continuous long-term discharge)
Overcharge Protection Current Value: 1A–50A ±0.1
Overcurrent Protection Delay: 0–8S ±1ms
Equalization Function Activation Voltage: 0–5V ±5mV
Equalization Current: 0–1000mA ±0.1uA
Single Cell Self-consumption: 0–4000uA ±0.1uA
Main Circuit Internal Resistance Test: 0–200mΩ ±1mΩ
Features
1. The number of series is optional from 1-24
2. Various protection and recovery function tests
3. Can choose the number of sections to be tested according to your own needs
4. Test results can be automatically saved
