Power supply: AC220V/50Hz, 1.5KW
Air source: 0.5MPa～0.8MPa
Heat pressing area: 200×200mm
Pressure: 1T, adjustable
Temperature control accuracy: ±2℃
Heating temperature: Room temperature ~ 200℃, adjustable
Parallelism of the two pressure plates: Within 0.05
Equipment size: 320mm × 325mm × 560mm
Weight: 90kg
1. The temperature of the work surface can be adjusted through the button on the thermostat panel. The current value and the set value of the set temperature can be displayed on the LCD display, which is intuitive and clear, with high temperature control accuracy and easy operation.
2. The pressure of the upper and lower working table can be adjusted by the pressure regulating valve to meet the requirements of different process parameters.
3. The machine adopts a single station structure, the upper and lower worktable panels are highly parallel, and the structure is stable and reliable.
4. The work surface is made of high-quality materials, with good heat transfer effect, saving power consumption and improving work efficiency.
5. Use light curtain protection device, safe to use.
6. This machine has a temperature abnormal alarm function.
7. Heat pressing time, temperature and pressure can be adjusted.
8. This machine adopts automatic and semi-automatic control, easy to operate.
9. Small size, can save space.
10. Exquisite appearance, the sheet metal adopts three-dimensional geometric design, which is simple and beautiful.
11. Electric control can be used for automatic operation during operation, and manual function can be used during debugging.
