Roller size: Diameter Φ96mm × 100mm
Roller hardness: HRC62
Roller finish: Ra0.4 or more
Roll cylindricity: ≤±2um
Rolling thickness: 0～2mm, adjustable gap
Heatable width: 100mm
Adjustable gap: 0～2mm
The thickness, speed and heating temperature can be adjusted
Roll placement: Vertical placement
Rolling temperature: Adjustable from room temperature to 130℃, digital display
Temperature control accuracy: ±0.5℃
Temperature resolution: 0.1℃
Power source: Voltage AC220V/50Hz, power 800W
Feeding speed: 0～40mm/s, adjustable speed
Dimensions: L505mm × W225mm × H325mm
Equipment weight: 60KG
1. Heating and rolling, the temperature is controlled by a thermostat, and the temperature is adjustable and displayed in numbers.
2. You can choose to work with or without heating.
3. The roller has high hardness, and the surface is plated with hard chrome, the hardness can reach HRC62 and it is anti-rust.
4. Adopt the inclined block to adjust the gap of the tablet, which has good self-control and high adjustment accuracy.
5. High rolling precision, roller cylindricity≤±2um.
6. Vertical design, convenient for feeding and rolling of strip material.
7. Adopt gear meshing rotation to realize the roller pressing.
8. appearance is exquisite and beautiful.
9. Electric rolling, forming automation, can be reversed operation.
10. Small size, easy operation, flexible and quick to use.
