Control/Display:: 5-inch color touch screen
Speed (r/min):: 0.1 – 200 stepless speed regulation, 2000 selectable speeds
Measurement Range (mPa.s):: R2-R7: 800 - 320M
URL: 25.6 - 2K
No. 21: 200 - 4M
No. 27: 1K - 20M
No. 28: 2K - 40M
No. 29: 4K - 80M
(K = 1000; M = 1000000)
Rotors:: 2 – R7 (6 rotors, standard)
R1 (optional)
Enhanced ultra-low viscosity adapter ULR (optional)
Small sample adapter (No. 21, 27, 28, 29 rotors) (optional
Sample Volume:: Rotors R1-R7: 500ml
ULR: Range 25.6 - 2000, 21ml
No. 21 rotor: 7.8ml
No. 27 rotor: 11.3ml
No. 28 rotor: 12.6ml
No. 29 rotor: 11.5m
Measurement Range (mPa.s):: ±1% (Newtonian liquid)
Repeatability Error:: ±0.2% (Newtonian liquid)
Shear Stress/Shear Rate Display:: Standard
Timing Function: Standard Real-time
Viscosity Curve Display: Shear rate vs viscosity curve
Temperature vs viscosity curve
Time vs viscosity curve
Kinematic Viscosity: Requires input of sample density
Temperature Measurement Function: Standard with temperature probe interface (requires optional temperature probe)
Auto Scanning Function: Scans and recommends the optimal rotor and speed combination
Maximum Measurement Range: Automatically displays the measurable viscosity range for the selected rotor and speed combination
Custom Measurement Programs: Can save up to 30 sets (including rotor, speed, temperature, time, etc.)
Data Storage: Can save up to 30 sets of data (including viscosity, temperature, rotor, speed, shear rate, shear stress, time, density, kinematic viscosity, etc.)
Printing: Data and curves can be printed (comes with a printing interface, printer optional)
Data Output Interface: USB: Can insert a USB drive to directly copy data
Thermostatic Components: Optional (includes various viscosity meter-specific thermostatic baths and cups)
Power Supply: Wide voltage range (110V / 60Hz or 220V / 50Hz)
Dimensions: 300*300 * 450 (mm)
1. Adopts ARM Technology with Built-in Linux System: The interface is simple and intuitive, allowing for quick and convenient viscosity testing through the creation of test programs and
data analysis.
2. Accurate Viscosity Measurements: Each range is automatically calibrated by a computer, ensuring high precision and minimal error.
3. Rich Display Information: In addition to viscosity (dynamic and kinematic viscosity), it also
displays temperature, shear rate, shear stress, the percentage of the measured value relative to
the full-scale value (with graphical display), range overflow alarms, automatic scanning, the
maximum measurement range under the current rotor-speed combination, date, time, and more. It can also display kinematic viscosity when the density is known, catering to different user
measurement needs.
4. Comprehensive Functions: Capable of timed measurements, user-defined 30 test programs, storage of 30 measurement data sets, real-time display of viscosity curves, and printing of data
and curves.
5. Front-Leveling Instrument: Allows for intuitive and easy leveling adjustments.
6. Stepless Speed Regulation:(1) RV1T Series: 0.3-100 RPM, with 998 speed settings. (2) RV2T Series: 0.1-200 RPM, with 2000 speed settings.
7. Displays Shear Rate vs. Viscosity Curves: Users can set the shear rate range, and real-time data is displayed on the computer. It can also display viscosity curves against time.
8. Standard USB Interface: Plug in a USB flash drive to directly copy data.
9. Optional Pt100 Temperature Probe: Offers a wide temperature range from -20°C to 300°C, with a temperature accuracy of 0.1°C.
10. Rich Optional Accessories: Includes dedicated viscosity meter thermostatic bath, thermostatic
cup, printer, standard viscosity samples (standard silicone oil), and more.
11. Bilingual Operating System (Chinese and English): Pre-configured before delivery.
