Measuring range and Accuracy (at 23*C±5*C)
Voltage measuring range/ Resolution/ Accuracy
DC0.000V～±50.000V/ 1mV/ within ±0.05％rdg±3digit
Range/ Measuring range/ Resolution/ Measuring current
20mΩ/ 0.00mΩ～25.00mΩ/ 10μΩ/ 100mA
200mΩ/ 0.0mΩ～250.0mΩ/ 100μΩ/ 10mA
2Ω/ 0.000Ω～ 2.500Ω/ 1mΩ/ 1mA
20Ω/ 0.00Ω～ 25.00Ω/ 10mΩ/ 100μA
200Ω/ 0.0Ω～ 250.0Ω/ 100mΩ/ 10μA
Accuracy: within ± (0.3％rdg＋50μΩ) ±2digit
Test signal: 1kHz±0.1% sine wave/applied voltage 1V r.m.s (max.)
Measuring method:4-terminal measuring method [available to contact check]
Sampling time:
[Free running mode] [FAST] 6 times per second [SLOW] 2 times per second
[Remote start mode] [FAST] 100msec. [SLOW] 450msec.
Measuring terminals max. voltage:DC±50V
Comparator set range:
Resistance：0000～2500 both high and low limit
Voltage：00.000～±50.000 both high and low limit
Indication of comparator's comparison result: LED indication LO/GO/HI and buzzer
Control signal
Input: Measurement start signal
Hold signal
Output：Judgment result signal [R-LO/R-HI/V-LO/V-HI/T-GO]
Contact signal error [CE]
Completion of the measurement signal [EOC]
Operation condition: [Temp.] +5℃～+40℃[Humidity] less than 85％
Power supply:AC100V～240V selectable, 50/60Hz, about 30VA
Outer dimension: about 260 (W) ×90 (H) ×250 (D) mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 2.6kg
