- Temperature Range:
0 ~ 120°C (32 ~ 248°F)
0 ~ 300°C (32 ~ 572°F)
100 ~ 500°C (212 ~ 932°F)
- Spectral Range: 8 ~ 14 μm
- Resolution: 0.1°C on interface,< 0.025% of temp. range at the analog output
- Emissivity ε: 95% (fixed)
- Measurement Uncertainty: 1.5% of temperature range or 2.5°C
- Repeatability: 1% of measured value or 1°C
- Noise (NETD, σ = 1): < 0.2°C
- Sighting: Eyepiece: Diopter type
Electrical:
- Power Supply: 18 ~ 30 VDC
- Output: 10 mV/°C or thermocouple type J or K
- Load: Min 50 kΩ
Communication and Interface:
- Exposure Time t90: 300 ms
- Connection Cable: 1 m
Environmental
- Protection system: IP 65 (DIN 40050)
- Ambient Temperature: 0 ~ 70°C (32 ~ 158°F) at housing
- Storage Temperature: -20 ~70°C (-4 ~ 158°F)
- Weight: 150 g
- Housing: Stainless steel
- CE Label: According to EU directives about electromagnetical immunity
