DC Voltage: 48V
Rated current: 10A
Current range: 0 ~ 10A
Rated power: 480W
Ripple&noise (max.): 150mVp-p
Voltage ADJ range: 48 ~ 55V
Voltage range: 90 ~ 264VAC 127 ~ 370VDC
Frequency range: 47 ~ 63Hz
Power factor (Typ.): PF>0.98/115VAC, PF>0.94/230VAC at full load
Efficiency (Typ.): 92.5%
AC Current (Typ.): 5A/115VAC 2.5A/230VAC
Overload: 105 ~ 130% rated output power
Over voltage: 29 ~ 33V
Working temp.: -20 ~ +70℃ (Refer to \"Derating Curve\")
Working humidity: 20 ~ 95% RH non-condensing
Storag temp.,humidity: -40 ~ +85℃, 10 ~ 95% RH
Temp. coefficient : ±0.03%/℃ (0 ~ 50℃)
Vibration: Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6
