CPU: Intel® 12th Gen Core™ i CPU socket-type (LGA1700) with Intel® R680E/ H610E chipset
Memory: up to 64 GB (32 GB per slot)
Graphics: Core i: Intel® UHD Graphics 770 Pentium/Celeron: Intel® HD Graphics 710
Ethernet: 2 x RJ45
Storage: 1 x 2.5inch HDD/SSD (up to 2 x 2.5inch SSD by optional kit; 2 x 3.5inch HDD by i-Module), 1 x SATA signal, 1x SATA power
Serial Ports: 2 x DB9, RS-232/422/485 support auto flow control; 4 x RS-232 (Optional)
USB: R680E: 2 x USB3.2 (Gen2), 6 x USB3.2 (Gen1), 1 x USB 2.0 (Internal) H610E: 4 x USB3.2 (Gen1), 4 x USB2.0
Audio: 2 (1 x line out and 1 x mic in)
Expansion Mini PCIe: R680E: 1 x mini PCIe, 1 x mini PCIe/mSATA H610E: 1 x mini PCIe, 1 x mSATA
Digital I/O: Supports Advantech i-Modules
Watchdog Timer: Programmable 1 ~ 255 sec/min
LED: 2 (1 x Storage and 1 x Power), 4 for COM1 TX/RX and COM2 TX/RX
Power Type: ATX/AT
Input Voltage: 9 ~ 36 VDC
Power Consumption: 45.7W ~108W
OS Support: Windows 10, Windows 10 IoT, Linux OS
Dimensions (W x H x D): 77 x 192 x 230 mm
Weight: 2.8 kg
Operating Temperature: 20 ~ 50 °C with 0.7 m/s air flow
Storage Temperature: -40 ~ 85 °C
Relative Humidity: 95% @ 40 °C (non-condensing)
Vibration: With SSD: 3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis With 2.5
Shock: With SSD: 20G, IEC-68-2-27, half-sine wave, 11 ms duration
