Accuracy Class : 0.1%
Linearity And Hysteresis : 0.1%
Nominal Load: 250 T
Temperature Effect (10 °C):
a) on zero: ≤ ± 0.028%
b) on sensitivity: ≤ ± 0.008%
Nominal Sensitivity: 2 mV/V
Calibration Tolerance: ≤ ± 0.1 %
Input Resistance: 800 ± 20 Ω
Output Resistance: 700 ± 2 Ω
Insulation Resistance: > 5 G Ω
Zero Balance: ≤ ± 1 %
Recommended Supply Voltage: 10 V
Nominal Supply Voltage: 1 ÷ 15 V
Max. Supply Voltage: 18 V
Mechanical Limit Values Referred To Nominal Load::
a) minimum load: 0%
b) service load: 120%
c) max permissible load: 150%
d) breaking load: > 300%
e) max transverse load: 50%
Reference Temperature: +23°C
Temperature Nominal Range: -10/+40 °C
Working Temperature: -20/+70 °C
Storage Temperature: -20/+80 °C
Weight: ~18 kg
Protection Class (En 60529): IP65
Execution Material: Stainless Steel
Connettore Connector : Connettore MIL 7 poli maschio
