Accuracy Class: OIML R60 : C2
Legal Divisions: 2000
Nominal Load (Emax): 30kg
Min. Verification Interval (Vmin): Emax / 10000
Combined Error: ≤ ±0.028%
Non-Repeatability: ≤ ±0.018%
Zero Return Over 30 Min.: ≤ ±0.030%
Creep To Nominal Load:
a) over 30 min.: ≤ ±0.029%
b) over 20 and 30 min.: ≤ ±0.009%
Temperature Effect (10 °C):
a) on zero: ≤ ±0.025%
b) on sensitivity: ≤ ±0.010%
Nominal Sensitivity: 2mV/V
Sensivity Tolerance: ≤ ±0.1%
Input Resistance: 420 ± 20Ω
Output Resistance: 350 ± 2Ω
Insulation Resistance: >5 GΩ
Zero Balance: ≤ ±1%
Recommended Supply Voltage: 10 V
Nominal Supply Voltage: 1-15 V
Maximum Supply Voltage: 18 V
Mechanical Limit Values Referred To Nominal Load::
a) minimum load: 0%
b) service load: 120%
c) max permissible load: 150%
d) breaking load: >300%
e) max transverse load: 200%
f) max permissible dynamic load: 75%
Displacement At Nominal Load: ∼ 0.4 mm
Reference Temperature: +23°C
Temperature Nominal Range: -10/+40 °C
Service Temperature: -20/+70 °C
Storage Temperature: -20/+80 °C
Weight : ∼1.0 kg
Protection Class (En 60529): IP67
Execution Material: Stainless Steel
Cable Length: 5m
Fixing Screws:
a) diameter: M6
b) resistance class: 12.9
c) tightening torque: 10 Nm
