Standard Version Indications
Type: RV
Full scale: 1.0 bar
Display: 1.0 bar
Resolution: 0.001 bar
Main Features:
Accuracy (Linearity And Hysteresis) : ≤ ± 0.20 % F.S. STANDARD versio
Pressure Units : bar
Temperature Indication: °C
a) Resolution: 0.1 °C
b) Accuracy: ± 1 °C
Reference Temperature: 0 … +50 °C
Operating Temperature: -10 … +60 °C
Relative Humidity: < 90 % not condensed
Temperature Effect (1 °C):
a) on zero: ≤ ± 0.005%
b) on sensitivity: ≤ ± 0.005%
Internal Resolution: 16 bit
Readings Per Second (0 Filter): 10 (100ms)
Digital Filter Programmable: 0 … 99
Resolution Programmable: 1, 2, 5, 10
Zero Function: Active up to 50% F.S.
Peak Function: 125 readings per second (8ms)
Baud Rate Programmable: 19200, 9600, 4800
Rs232C Connection (Option): DB9 female connector
Display : 16 mm (custom LCD)
Power Supply: NOT RECHARGEABLE inside BATTERY
Autonomy: ∼ 1 YEAR
Battery: n° 2 to 1.5V size AAA
Data Logger Function:
Max Storing Frequency: 1 measure for second
Max Storing Pressure Measures: 60.000 Records
Max Storing Pressure+ Temperature: 30.000 Records
Mechanical Limit Values:
a) service pressure: 100% F.S.
b) limit pressure: 150% F.S.
c) breaking pressure: >300% F.S.
d) highly dynamic pressure: 75% F.S.
Process Coupling: 1/2" G Male
Seal Recommended: USIT A 63-18
Tightening Wrench: 27 mm
Tightening Torque: 28 Nm
Protection Class (EN 60529): IP40
Material Sensor: INOX 17-4 PH
Container Material: ABS
