Static Nominal Torque: 5 N·m
Linearity And Hysteresis : ≤ ± 0.20 % (see options)
Temperature Effect (1°C):
a) on zero: ≤ ± 0.02%
b) on sensitivity: ≤ ± 0.02%
Nominal Sensitivity: 2mV/V (*0.5N·m: 1mV/V)
Sensivity Tolerance: ≤ ± 0.5%
Input Resistance: 825 ± 50Ω
Output Resistance: 700 ± 2Ω
Nominal Power Supply: 1-15V
Max. Power Supply: 18V
Insulation Resistance: >2 GΩ
Zero Balance: ≤ ± 1%
Limit Mechanical Values Referred To Nominal Torque::
a) service torque: 100%
b) max. permissible torque: 150%
c) breaking torque: >300%
d) highly dynamic torque: 70%
Reference Temperature: +23°C
Working Temperature Range: -10/+70°C
Storage Temperature Range: -20/+80°C
Protection Class (En 60529): IP40
Sensor Execution Material: INOX 17-4 PH
Electrical Connection: Cavo / Cable 5m
Process Coupling (Uni Iso 1174-1): 1/4” male
