Output form: Single output
Bandwidth（-3dB）: DC~500kHz
Maximum output voltage: 310Vp-p(±155Vp)
Maximum output current: 1Ap(DC-50Hz), 2.82Ap，2Arms（50Hz~500kHz）
Maximum output power: 437.1Wp
Fuse: 10A/250V
Voltage gain: x0~100(0.1step)
Load RL upper limit: ≥54.8Ω (above 50Hz)
Output impedance: 0.5Ω＋1.6uH
Slew Rate: 400V/μs
DC bias: ±150V(0.1Vstep)
Input impedance: 50Ω / 5kΩ
Input amplitude: 0~10Vp-pMAX
Output voltage error: ≤±3%FS@1kHz
Voltage monitoring: 100:1（±5%）
Total harmonic distortion （THD）: ≤0.1%@1kHZ，100Vp-p
Output voltage zero-point drift: ≤0.1V
Output Connector: 4mm Banana socket
Protection: Overcurrent protection
Signal Ground: It is connected with the grounding of the shell and the power line
Supply voltage: AC220V±10%，50Hz
Operating temperature: 0℃~45℃
Storage temperature: -20℃~50℃
Humidity: ≤80% RH，no condensation
Size(W * H * D): 440*290*470mm
