AC withstand voltage (ACW): None
DC withstand voltage (DCW): None
Insulation resistance (IR): None
Ground resistance (GB): None
Leakage current (LC): 20mA Leakage current, MD-C/unweighted C/E network (up to 8 networks); AC/DC RMS and peak measurement.
Multi-channel switching: (Opional extemal switching unit 8 for ACWIDCW, 8 for LC, 1 for GB)
DUT power supply Auxiliary voltage: External isolation power supply is required, (optional built-in 500VA variablefrequency power supply)
HMI: Android platform, 10" touchscreen, RS232/LAN/USB/BARCODE/PLC/ALARM/REMOTE/HDMl (optional) interface
Standard accessories: Test box (3m), test clamp (3m),foot switch (2.5m), alarm lamp (0.8m), auxiliary power cable (1.9m)
Optional accessories: (PC, ESRS software, spot check device,,barcode scanner, label printer, HDMl monitor, wireless keyboard/mouse)
Dimensions (mm) (W×H×D): 426×177×550
