Input:
Voltage: 3-phase 3-wire + PE, 340V ~ 420VAC
Frequency: 47 ~ 63 Hz
Output:
Voltage: 0～300V
Current: 0～100A
Power: 10kW
Display Mode: 4.3” Color LCD Screen
Measurement Accuracy:
Voltage: ≤0.1% Umax, Resolution: 0.01V
Current: ≤0.2% Imax, Resolution: 0.01A (>1000A, 0.1A)
Power: ≤1% Pmax, Resolution: 0.001kW (>100kW, 0.01kW)
Ripple & Noise (20Hz ~ 20MHz):
Vrms: 60mV
Vpp: 450mV
Load Effect:
Voltage: ≤0.05% Umax
Current: ≤0.15% Imax
Power Effect:
Voltage: ≤0.02% Umax
Current: ≤0.05% Imax
Response Time:
Transient Response Time: ≤2ms
Rise Time to 100%: 50ms (10% - 90%)
Maximum Output Voltage Compensation: 6.5V
Communication Interface: RS232
Environmental Conditions:
Operating Temperature: 0 ～ 40℃
Humidity: 20 ～ 90% RH
Physical Specifications:
Dimensions (W × H × D): 440 × 133 × 600 mm
Weight: 27kg
