Amphenol FCI 10124632-3041N01LF DDR4 DDR4 DIMM connector Vertical Through Hole 288 Position 085mm (0033in) Pitch
Manufacturer: Amphenol FCI Model: 10124632-3041N01LF - Contact
Pitch: 0.85 mm
Key Type: Right
Tail Length: 2.1 mm
Current Rating: 750 mA
Mounting Angle: Vertical
Mounting Style: PCB Mount
Voltage Rating: 1.2 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Through Hole
Number of Positions: 288 Position
Insulation Resistance: 1 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
