Color: White
Width: 21 mm
Gender: Receptacle (RP - Male)
Height: 24.4 mm
Length: 46.2 mm
Dimensions: 43.2 mm x 21 mm x 24.4 mm
Insulation: Insulated
Contact Type: Pin (Male)
Mating Gender: Plug
Contact Gender: Without Pin Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Thermoplastic (TP)
Wire Gauge Range: 14 AWG to 20 AWG
Mating Part Number: AT04-3S
Number of Positions: 3 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
