Width: 5.9 mm
Height: 9 mm
Length: 5.9 mm
Fall Time: 14 us
Rise Time: 14 us
Wavelength: 870 nm
Unit Weight: 0.400 mg
Dark Current: 200 nA
Light Current: 6.3 mA
Mounting Style: Through Hole
Peak Wavelength: 870 nm
Lens Color/Style: Black
Pd - Power Dissipation: 200 mW
Half Intensity Angle Degrees: 10 deg
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
Maximum On-State Collector Current: 50 mA
Collector- Emitter Voltage VCEO Max: 70 V
Collector-Emitter Breakdown Voltage: 70 V
Collector-Emitter Saturation Voltage: 150 mV
