Technology: GaAs
IF Frequency: DC to 10 GHz
LO Frequency: 7 GHz to 22 GHz
RF Frequency: 7 GHz to 22 GHz
Mounting Style: SMD/SMT
NF - Noise Figure: 13 dB
Conversion Loss - Max: 14 dB
Pd - Power Dissipation: 189 mW
P1dB - Compression Point: 11 dBm
OIP3 - Third Order Intercept: 20 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
