Width: 15.49 mm
Height: 4.2 mm
Length: 37.85 mm
Gain Error: 0.125 %FSR
Input Type: Single-Ended
Resolution: 12 bit
Unit Weight: 1.140 g
Architecture: SAR
Input Voltage: 10 V/20 V, +/- 5 V/+/- 10 V
Sampling Rate: 100 kS/s
Interface Type: Parallel
Mounting Style: Through Hole
Reference Type: External, Internal
Sample and Hold: Yes
Power Consumption: 385 mW
Number of Channels: 1 Channel
Number of ADC Inputs: 2 Input
Number of Converters: 1 Converter
Supply Voltage - Max: 5 V, 15 V
Supply Voltage - Min: 5 V, 15 V
Pd - Power Dissipation: 575 mW
Operating Supply Voltage: 5 V, 15 V
INL - Integral Nonlinearity: +/- 1 LSB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
