Width: 7.87 mm
Height: 3.56 mm
Length: 32.51 mm
Gain Error: +/- 5 LSB
Input Type: Single-Ended
Resolution: 12 bit
Architecture: SAR
Input Voltage: +/- 5 V/+/- 10 V
Sampling Rate: 500 kS/s
Interface Type: 3-Wire, Parallel
Mounting Style: Through Hole
Reference Type: External, Internal
Sample and Hold: Yes
Power Consumption: 60 mW
Number of Channels: 1 Channel
Number of ADC Inputs: 1 Input
Number of Converters: 1 Converter
Supply Voltage - Max: 5 V
Supply Voltage - Min: 5 V
Pd - Power Dissipation: 95 mW
Operating Supply Voltage: 5 V
INL - Integral Nonlinearity: +/- 1 LSB
SNR - Signal to Noise Ratio: 70 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
DNL - Differential Nonlinearity: +/- 1 LSB
