Width: 7 mm
Height: 1 mm
Length: 7 mm
Gain Error: +/- 2.5 LSB
Input Type: Differential/Pseudo-Differential/Single-Ended
Resolution: 12 bit
Unit Weight: 72.800 mg
Architecture: SAR
Input Voltage: 2.5 V/5 V
Sampling Rate: 2 MS/s
Interface Type: Microwire, QSPI, SPI
Mounting Style: SMD/SMT
Reference Type: External, Internal
Development Kit: EVAL-AD7266EDZ
Sample and Hold: Yes
Moisture Sensitive: Yes
Number of Channels: 6 Channel
Number of ADC Inputs: 12 Input/6 Input
Number of Converters: 2 Converter
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 2.7 V
Pd - Power Dissipation: 33.6 mW
Operating Supply Voltage: 2.7 V to 5.25 V
INL - Integral Nonlinearity: +/- 1.5 LSB
SNR - Signal to Noise Ratio: 71 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: - 0.99 LSB/1.5 LSB
