Width: 3 mm
Height: 0.83 mm
Length: 3 mm
Supply Type: Single Supply, Dual Supply
Unit Weight: 3 mg
Configuration: 2 x SPDT
On Time - Max: 150 ns
Mounting Style: SMD/SMT
Off Time - Max: 90 ns
Moisture Sensitive: Yes
Number of Channels: 2 Channel
On Resistance - Max: 190 Ohms
Supply Current - Max: 230 uA
Supply Voltage - Max: 16.5 V
Supply Voltage - Min: 5 V
Pd - Power Dissipation: 3.5 mW
Switch Continuous Current: 25 mA
Maximum Dual Supply Voltage: +/- 16.5 V
Minimum Dual Supply Voltage: +/- 5 V
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
