Analog Devices ADUC848BSZ62-3 8-bit Microcontrollers - MCU 10 Channel 16 Bit ADC + Flash 8 Bit uP

Core: 8052

Width: 10 mm

Height: 2 mm

Length: 10 mm

Unit Weight: 496 mg

Data RAM Size: 2.25 kB

Data RAM Type: RAM

Data ROM Size: 4 kB

Data ROM Type: EEPROM

ADC Resolution: 16 bit

DAC Resolution: 12 bit, 16 bit, 16 bit

Data Bus Width: 8 bit

Interface Type: I2C/SPI/UART

Mounting Style: SMD/SMT

Number of I/Os: 34 I/O

Watchdog Timers: Watchdog Timer

Processor Series: ADUC848

Moisture Sensitive: Yes

Program Memory Size: 62 kB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 2.7 V

Analog Supply Voltage: 3 V

Number of ADC Channels: 10 Channel

Maximum Clock Frequency: 12.58 MHz

Number of Timers/Counters: 3 Timer

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
