Technology: GaAs
Unit Weight: 21.400 mg
IF Frequency: DC to 4.5 GHz
LO Frequency: 22 GHz to 32 GHz
RF Frequency: 22 GHz to 32 GHz
Mounting Style: SMD/SMT
Development Kit: EV1HMC524ALC3
NF - Noise Figure: 15 dB
Moisture Sensitive: Yes
Conversion Loss - Max: 13 dB
Pd - Power Dissipation: 560 mW
P1dB - Compression Point: 17 dBm
OIP3 - Third Order Intercept: 18 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
