Gain: - 0.5 dB
Technology: Si
Unit Weight: 1 g
IF Frequency: 1 GHz
LO Frequency: 750 MHz to 4.3 GHz
RF Frequency: 900 MHz to 3.9 GHz
Mounting Style: SMD/SMT
NF - Noise Figure: 12 dB
Operating Supply Current: 226 mA
Operating Supply Voltage: 3.15 V to 3.6 V
P1dB - Compression Point: 10.7 dBm
OIP3 - Third Order Intercept: 23.2 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
