Gain V/V: 200 V/V
Shutdown: No Shutdown
Gain Error: 0.15 %
Technology: Si
Output Type: Rai to Rail
Settling Time: 20 us
3 dB Bandwidth: 80 kHz
Amplifier Type: High Side Current Sense Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 0.3 V/us
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.7 V
Pd - Power Dissipation: 387.8 mW
Ib - Input Bias Current: 200 nA
Operating Supply Current: 1.3 mA
Vcm - Common Mode Voltage: 0 V to 76 V
Ios - Input Offset Current: 200 nA
Vos - Input Offset Voltage: 500 nV
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 95 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 130 dB
PSRR - Power Supply Rejection Ratio: 110 dB
