Capacity: 320 g
Readability: 0.001 g
Repeatability (std. deviation): 0.001 g
Linearity: ±0.002 g
Accuracy after external calibration: ± 0.010 g
Stabilization Time: ~ 1 sec (~0.8 sec for 5 g)
Sensitivity drift: ±2 ppm / ˚C (10 ˚C to 30 ˚C / 50 ˚F to 86 ˚F, when automatic self-calibration is OFF)
Display: Reverse Backlit LCD (Character height: 17.8 mm)
Display Refresh Rate: 5 times / second, 10 times / second or 20 times / second
Units of Measure: g (gram), oz (ounces), lb (pound), lb-oz (pound-ounce), ozt (troy ounce), ct (metric carat), mom (momme), dwt (pennyweight), gr (grain),
pcs (counting mode), % (percent mode), SG (specific gravity), and a user-programmable unit.
Counting mode:
Min unit mass: 0.001 g
Number of samples: 5, 10, 25, 50 or 100 pieces
Percent mode:
Min 100% ref mass: 0.100 g
Min 100% display: 0.01%, 0.1% or 1% (depends on the reference mass stored)
Operating environment: 5 ˚C to 40 ˚C / 41 ˚F to 104 ˚F, 85% R.H. or less (no condensation)
Power supply / consumption: AC adapter / approx. 30 VA
Communication Interface: Standard: RS-232C and USB Optional: Quick USB, LAN Ethernet (FXi-08), USB Host (GXA-24), Bluetooth Converters: AD-8529PC-W, AD8529PR-W
Weighing pan size: 128 mm × 128 mm / 5 × 5 in
Dimensions (W × D × H): 212 (W) × 317 (D) × 93 (H) mm / 8.3 (W) × 12.5 (D) × 3.7 (H) in
Net weight: Approx. 5 kg / 11 lb
Weighing Applications: Counting with ACAI, % Weighing, Animal Weighing, Density Determination, Statistical Calculation, Comparator HI|OK|LO, Underhook, Gross/Net/Tare
