Measuring range
Density: 0 g/cm³ to 3 g/cm³
Sound Velocity: 1,000 m/s to 2,000 m/s
Temperature: 0 °C to 100 °C (32 °F to 212 °F)
Pressure: 0 bar to 8 bar (0 psi to 116 psi)
Accuracy*
Density: 0.000005 g/cm³
Temperature: 0.01 °C (0.02 °F)
Repeatability s.d.**
Density: 0.000001 g/cm³
Sound Velocity: 0.1 m/s
Temperature: 0.001 °C (0.002 °F)
Reproducibility s.d.**
Density: 0.000005 g/cm³
Sound Velocity: 0.5 m/s
Digital resolution
Density: 0.000001 g/cm³
Sound Velocity: 0.01 m/s
Dimensions (L x W x H): 526 mm x 347 mm x 230 mm (20.7 in x 13.7 in x 9 in)
Weight: 22.62 kg (49.87 lbs)
Power supply: AC 100 to 240 V, 50/60 Hz, fluctuation ± 10 %, 190 VA
Display: 10.1" TFT WXGA (1280 x 800 px); PCAP touchscreen
Controls: Touchscreen, optional keyboard, mouse, and barcode reader
Communication interfaces: 4 x USB, Ethernet, CAN, RS232
Internal storage: 10,000 measuring values including camera images
* According to ISO 5725
** Under ideal conditions and for low viscosities
