Stations: 2
Cylinder sizes accommodated: 250 mL standard 5, 10, 25, 50, 100, 250, 500, 1,000 mL¹
Tap speed: User configurable 50 to 350 taps/minute
Drop height: 3 mm (0.12 inch) ± 0.2 mm or 14 mm (0.55 inch) ± 1 mm
Sound level: 65 dB (58 dB with optional noise reduction cabinet)
Tap mode: User configurable by time (1 second to 999 minutes) or number of taps (1 to 99,999)
User interface: 7-inch TFT WVGA (800 x 480 pixels); PCAP touchscreen
User management: Included (with password protection)
USB ports: 2
Supported input devices: Barcode reader, keyboard, mouse, touchscreen
Balance and printer connection: Yes (via USB port)
Built-in calculations: Bulk density, Carr’s compressibility index, Hausner ratio, tapped density
Storage capacity: 1,000 reports/100 methods
Built-in methods: 24
Physical And Utilities:
Dimensions : Height: 228.6 mm (9 inches) no cylinder/vessel, 188 mm (7.4 inches) to top of housing
Width: 263.5 mm (10.4 inches)
Depth: 361 mm (14.2 inches)
Weight : 17.6 kg (38.7 pounds)
Electrical:
Voltage-External AC/DC adapter: Input AC: 100-240 V, 1.3 A
Frequency: 50 / 60 Hz
Instrument input: 24 VDC, 2.6 A, 63 W
Over-voltage category: I (for the instrument)
Connection : Grounded, single-phase outlet
Environmental:
Temperature : 15 °C - 40 °C (59 °F - 104 °F)
Relative humidity: 10%-80% RH non-condensing
¹ The 500 and 1,000 mL graduated cylinders require the large platform and corresponding TruLock straps (sold separately
