Input
Input voltage range: 90 - 264 Vac; 127 - 350 Vdc
Frequency: 47 - 63 Hz (360 - 440 Hz with higher leakage)
Inrush current: 50 Apk, cold start
Leakage current: <300 µA (using UL test method)
No load power: < 500 mW
Output
Maximum power:
650 W, forced-air cooling (750 W peak)
400 W, free-air natural convection cooling (650 W peak)
Adjustment range: -0% / +15%
Holdup time: 20 ms @ 400 W
Environmental Specifications
Operating temperature: -20 °C to +80 °C (derate at 50 °C), startup at -40 °C
Storage temperature: -40 °C to +85 °C
Operating humidity: 5% to 95% (non-condensing)
Non-operating humidity: 5% to 95% (non-condensing)
Function: Fan output, Standby output, Overtemperature protection, Overload protection, Overvoltage protection, Smart fan control, Remote sense, Current share, Serial bus interface: PMBus®
Ordering Information
Output Voltage: 12 V
Vout Adjust Range (-0% /+15%): 12 - 13.8 V
Minimum Load: 0 V
Max. Continuous Load (Free Air): 33.3 A
Max. Peak Load (Free Air): 54.2 A
Max. Continuous Load (Forced Air): 54.2 A
Max. Peak Load (Forced Air): 62.5 A
Regulation: ±2%
Ripple (p-p): 120 mV
