Nominal Main Output: 12 V @ 133.3 A
Standby Output: 12 V @ 3.5 A
Airflow Direction: Standard (forward)
Input voltage range: 180 to 264 Vac: 1600 W; 90 to 140 Vac: 800 W
Frequency: 47 Hz to 63 Hz
Max input current: 10.8 Arms
Main DC Output
Nominal setting: MIN: -0.20%/NOM: 12/ MAX: 0.20%
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 2 A/ MAX: 133.33 A
Standby DC Output
Nominal setting: MIN: -3%/ NOM: 12/ MAX: 3%
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0.1 A/ MAX: 3.5 A
Functions: Overcurrent protection; Overvoltage protection; Undervoltage protection
Operating temperature:
Ds1600SPE-3: 1600W from 0 to 50 °C, can operate up to 65°C at 2% derated power for every °C above 50°C
DS1600SPE-3-001: 1600W from 0 to 40°C, can operate up to 60°C at 1% derated power for every °C above 40°C
Operating relative humidity 5% to 95% non-condensing
