Input
Input range: 90 - 264 Vac
Frequency: 47 Hz to 63 Hz
Efficiency: 94.0% peak
Max Input current: 10.0 Arms @ 90 Vac
Output
Main DC Output:
Nominal setting: MIN: -0.20%/ NOM: 12/ MAX: 0.20%
Total output regulation range： MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0.5 A/ MAX: 62.5 A
Standby DC Output:
Nominal setting: MIN: -1%/ NOM: 12/ MAX: 1%
Total output regulation range: MIN: 11.4 V/ MAX: 12.6 V
Output current: MIN: 0.1 A/ MAX: 3.0 A
Protection: OVP, OCP, Short Circuit, OTP
Operating temperature: 0 to 50 °C, withstand operation up to 60 °C at full power without damage
Operating relative humidity: 20% to 80% non-condensing
Non-operating temperature: -40 to +70 °C
Non-operating relative humidity: 10% to 95% non-condensing
Nominal Main Output: 12 V @ 62.5 A
Standby Output: 12 V @ 3 A
Airflow Direction: Standard (forward)
