Artesyn ERM04A36B Railway DC-DC Converter (5V; 4A; 20W)
Manufacturer: Artesyn Model: ERM04A36B - Contact
Input range: 18 - 75 Vdc
Output: 5 V @ 4 A
Efficiency @ Max Load: 85%
Max Power: 20 W
Voltage tolerance: ±1.0%
Line regulation: ±0.2%
Load regulation: Single output: ±0.5%; Dual output ±1.0%
Noise/ripple: 150 mV
I/O isolation: 3000 Vac rms min.
Operating ambient temperature range: -40 °C to +85 °C (with derating)
Storage temperature: -50 °C to +125 °C
Humidity: 5% to 95% (non-condensing)
