Width: 107.95 mm (4.25 in)
Height: 45.72 mm (1.8 in)
Length: 177.8 mm (7 in)
Efficiency: 70 %
Unit Weight: 600 g
Output Power: 110 W
Input Voltage: 85 VAC to 264 VAC, 120 VDC to 370 VDC
Cooling Method: Convection, Air-Cooled
Mounting Style: Chassis
Input Frequency: 47 Hz to 440 Hz
Load Regulation: Regulated
Mechanical Style: Open / Enclosed Frame
Isolation Voltage: 3 kVAC
Number of Outputs: 4 Output
Power - Convection: 80 W
Power - Forced Air: 110 W
Input Voltage - Max: 264 VAC, 370 VDC
Input Voltage - Min: 85 VAC, 120 VDC
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 8 A
Output Current-Channel 3: 4.5 A
Output Current-Channel 4: 500 mA
Output Voltage-Channel 1: 5.1 VDC
Output Voltage-Channel 2: 24 VDC
Output Voltage-Channel 3: 12 VDC
Output Voltage-Channel 4: - 12 VDC
Operating Temperature Range: 0 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
