Sensing side diameter: 12mm
Sensing distance: 2mm
Hysteresis(distance): Max. 15% of sensing distance
Standard sensing target: 12×12×1mm(iron)
Response frequency: 100Hz
Indicator: Operation indicator (red LED)
Weight: Approx. 110g(approx. 83g)
Power supply: 12 - 24 VDC(ripple P-P: ≤ 10 %), operating voltage: 10 - 30 VDC
Current specification: Leakage current: Max. 0.8mA
Control output: 3 to 100 mA
Residual voltage: Max. 3.5V
