Applicable fluid : (Fluid type) Air, Non-corrosive gas and fluid that will not corrode Stainless steel 316L
Pressure port direction : bottom fitting
Rated pressure range: -101.3 ~ 100.0kPa
Control output: NPN open collector
Pressure port : NPT1/8
Connection type : Connector type(connector type cable: 2m)
Pressure type : compound pressure
Power supply : 12-24VDC ±10%(ripple P-P: max. 10%)
Current consumption : Voltage output type: Max. 50mA
Current output type: Max. 75mA
Protection structure : IP40
