Bachmann FM221 FASTBUS Module (1 FO interfaces, 50/62.5 µm)

FASTBUS master module with 1 FO interface

50/62.5 µm Multimode 2000 m; LC connector

FASTBUS Interface

Cable length 2000 m between the stations

Total length max: 2300 m

Transmission medium Multimode fiber (50/125 μm and 62.5/125 µm) max. 2000 m

FOC connector type LC

FOC guide wavelength 1310 nm

Max. number of stations 16 (max. 10 per line)

Link budget > 8 dB (3 dB reserve)

Integrated power supply

Input voltage 24 V DC (18 V to 34 V)

Nominal power (Output) 18.25 W

Output current at +5 V 3000 mA

Output current at +15 V 250 mA

Output current at -15 V 200 mA

Diagnostics

Fiber optics – received light output

HW: three-color status LED

SW: 0 % – 100 %

Environmental conditions:

Standard:

Operating temperature: -30 °C to +60 °C

Relative humidity, operation: 5 % to 95 % noncondensing

Storage temperature : -40 °C to +85 °C

Relative humidity storage: 5 % to 95 % with condensation

Pollution degree (IEC 60664-1) 2 (noncondensing)
