Resolution (H x V Pixels): 3088 x 2064
Resolution: 6.3 MP
Sensor Type: Sony IMX178LQJ-C / Progressive scan CMOS / Rolling shutter
Sensor Format: 1/1.8 inch
Effective Sensor Diagonal: 8.92 mm
Pixel Size (H x V): 2.4 x 2.4 µm
Frame Rate (at Default Settings): 16.9 fps
Mono / Color: Color
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈2.9 W (typical) when using Power over Ethernet / ≈2.5 W (typical) @ 12–24 VDC when supplied via I/O connector
I/O Lines: 1 opto-coupled input line / 1 opto-coupled output line / 1 general purpose I/O (GPIO) line
Lens Mount: C-mount
Size (L x W x H): 42.0 x 29 x 29 mm (without lens mount or connectors) / 60.3 x 29 x 29 mm (with lens mount and connectors)
Weight: <90 g
