Test mode: Fixed voltage, Fixed current, Fixed power, Fixed resistance
Display mode: 20*2LCD’s clear and direct display with backlight
Maximum input voltage: 360V
Maximum input current: 60A
Maximum input power: 900W
Voltage accuracy: 0.1%+0.03%FS
Current accuracy: 0-6A/12A :±0.1%+0.1%FS
0-60A/120A:±0.2%+0.15%FS
Minimum analysis: Voltage 1mV; Current 1mA
List test function: Rated voltage, Rated current, Rated power, Rated resistance, SHORT, OPEN
Battery test function:
- Input:2-120V/360V; Max measurement capacity: 999A/H
- Timer range: 1~60000sec
Dynamic measurement function: Range of Frequency 0.1Hz-1KHz
Remote measurement function: Available
Standard RS232C interface: Available
Protection mode: Over-voltage, Over-current, Over-power, Over-temperature, Opposite polarity
Working temperature & humidity: 0℃~40℃, ≤90%RH
Power requirement: 198-242VAC 99V-121VAC 47.5-63Hz
Power consumption: ≤40VA
